Autoprint Blankmatic 106 – 2HWR
Quick Specifications
Print Speed
1 – 20 (Max.) times / min
Resolution
NA
Media Width
1080 x 780 mm
Power
360 – 420 V
High-Efficient
Increases the operator efficiency by reducing their body fatigue during feeding
Superior Quality
Machine is equipped with PLC and touch screen interface for operation which makes it safe and user friendly
Great Features
Mechanical Limit switch for X & Y axis servo in addition to the non contact sensor, for extra safety. Additional emergency stop is provided for the moving arm assy.
Safe
The electrical and electronic parts of the machine are all imported and branded which makes them reliable and safe for operation.
Budget-Friendly
Cost-effective machine.
Sensor System
Pin blocking sensor.
Technical Specifications
Specifications
Bench Height
850 mm
Max. Pressure
100 Bar
Power Consumption
6 kW
Air Compression
4 – 6 Bar
Air Consumption
2 L/min
Input Power
3 Phase
Media Handling
Max. Sheet Size (X, Y)
1080 x 780 mm
Min. Sheet Size (X, Y)
420 x 400 mm
Max. Stripping Size
500 x 500 mm
Min. Stripping Size
30 x 30 mm
Min. – Max. Pile Height
45 – 85 (Max.) mm
Stripping Speed
1 – 20 (Max.) times / min
Featured Video
Autoprint Blankmatic 106 - 2HWR
